3-4 3120827
SECTION 3 SIZZOR ARMS
S
E
C
T
I
O
N
3
S
I
Z
Z
O
R
A
R
M
S
130 0200404 Arm Weldment (3rd Outboard) 2
131 0200465 Arm Weldment (Top Outboard) 1
132 1320061 Clamp, Hose 4
133 0641508 Bolt 5/16"-18NC x 1" 4
134 Not Used
135 Pin, Keeper A/R
3841144 Prior to June 1993 2
3841203 June 1993 to S/N44841 2
Not Required S/N44841 to Present 0
136 3340674 Pad, Mounting Block 2
137 Bushing, Spacer 2
0961335 Prior to June 1993
0961785 June 1993 to Present
138 0641624 Bolt 3/8"-16NC x 3" 8
139 4751600 Flatwasher 3/8" 16
140 3311605 Locknut 3/8"-16NC 8
141 0961664 Bushing, Composite 26
142 4740229 Washer, Bronze 2
143 0641526 Bolt 5/16"-18NC x 3 1/4" 19
144 0641608 Bolt 3/8"-16NC x 1" 2
145 4740401 Washer, Special 2
— — — — — — — — — — —
2901331 Sizzor Arm Kit - 40RTS (Includes Items
4,7,8,9,10,1112,20,23,25,30 & 31) 1
0252588 SIZZOR ARM PADS INSTALLATION Ref. 3
201 Pad Options: 32
3340841 Prior to S/N 53927
3340848 S/N 53927 to Present
FIGURE 3-1. SIZZOR ARMS INSTALLATION - 40RTS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
