2-58 3120827
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
29 4360274 Switch, Push Button (Start) 1
30 0100035 Loctite #222 (Not Shown) A/R
31 3790012 O-Ring (Prior to S/N 74818 Only) A/R
32 4360284 Switch, Key (Select) (CE Spec) (Prior to
S/N 65031) 1
4360468 Switch, Key (Select) (CE Spec) (S/N 65031 to
Present) 1
4360290 Switch, Key (Select) (Australian Spec) (Prior to
S/N 65031) 1
4360469 Switch, Key (Select) (Australian Spec) (S/N 65031
to Present) 1
7010698 Key, Replacement (4360284 & 4360290) 1
2860030 Key, Replacement (4360469 & 4360468)
33 Switch, Push/Pull (Emergency Stop) Options: 1
4360289 Prior to S/N 65031
4360475 S/N 65031 to Present
34 4360314 Switch, Toggle (Lift) 1
35 2600161 Hinge 1
36 3911008 Screw, Machine #10-24NC x 1 1/2" 7
37 Block, Contact Options: A/R
Not Required Prior to April 1993 0
4460267 April 1993 to S/N 81217 1
4360478 S/N 81217 to Present 1
38 3300177 Nut, Tinnerman 2
39 4740120 Washer, Nylon 5
40 0750806 Screw, Round Head 2
41 4460303 Terminal, Ground Block (Not Shown) 1
42 Not Used
43 Oil Pressure Gauge Assembly Options: 1
2420111 Deutz Engine Machines
2420164 Ford Engine Machines
2420084 Gauge Light Kit 1
44 Water Temperature Gauge Assembly Options: 1
3520070 Deutz Engine Machines (Hole Plug)
2420159 Ford Engine Machines
2420084 Gauge Light Kit 1
45 Not Used
46 Breaker, Circuit Options: 1
4360212 Deutz Engine Machines (3 Amp)
Not Required Ford Engine Machines
47 1701683 Decal, Relay Function 1
48 Block, Contact Options: 1
See Note Prior to S/N 28604 (Note: Use 4360267 as
replacement for original 4360237)
4360267 S/N 28604 to S/N 81217
Not Required S/N 81217 to Present
49 4360281 Block, Contact 1
FIGURE 2-13. GROUND CONTROL BOX INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
