SECTION 4 PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
30
3760170
Ring (S/N 55667 to Present)
8
31
Not Used
32
4060807
Shield, Flex Trim (Not Shown) (S/N 101993 to Present)
1.25’/.4m
--------------------------------------------------------------------
2902029
Kit, Platform Rails (Includes Items 1, 2 & 11)
1
2902028
Kit, Platform Rails (Includes Items 1, 2, 11 & 19)
1
OPTIONAL WORKLIGHTS INSTALLATIONS
Ref.
0253792
25RTS
Ref.
—
0253793
33RTS
Ref.
—
0253794
40RTS
Ref.
—
101
2920111
Worklight
2
7016627
Bulb, Replacement (1 per Assembly)
2
102
4460206
Terminal, Male
2
103
4460185
Terminal, Female
2
104
1060341
Cable, Electrical - 16/2
A/R
25RTS
80ft/24.4m
33RTS
94ft/28.7m
40RTS
100ft/30.5m
105
4240033
Tie Strap
10
106
0901930
Bracket, Mounting
2
107
0641416
Bolt 1/4"-20NC x 2"
2
108
4751400
Flatwasher 1/4"
2
109
4761400
Lockwasher 1/4"
2
110
3311401
Nut 1/4"-20NC
2
0250999
OPTIONAL WELDED ON ATTACH RINGS
INSTALLATION
Ref.
2
201
3534309
Plate (Welded on Parts)
2
202
3760274
Ring, Swivel
2
0253850
OPTIONAL BOLT-ON ATTACH RINGS
INSTALLATION
Ref.
A
251
3760321
Ring, Swivel
6
252
0630476
Screw, Button Head 5/16"-18NC x 1 1/4"
24
253
4761500
Lockwasher 5/16"
24
254
0100011
Loctite #242 (Not Shown)
A/R
0250317
OPTIONAL CIRCULAR LEVEL INSTALLATION
Ref.
—
301
4842981
Mounting Weldment
1
302
2420038
Level, Circular
1
303
3910610
Screw, Machine #6-32NC x 5/8"
3
304
4770600
Starwasher #6
3
305
0641406
Bolt 1/4"-20NC x 3/4"
4
306
3311401
Nut 1/4"-20NC
4
FIGURE 4-1. FIXED PLATFORM (STANDARD) & OPTIONAL COMPONENTS INSTALLATIONS
(CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
