JLG 40RTS Parts Manual User Manual
Page 192
7-4
3120827
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
LEVELING JACKS ELECTRICAL DIAGRAM
(OPTIONAL)
Ref.
0254076/1282105
With Interlock (CE Spec)
Ref.
C/D
4932810
Without Interlock (Australian Spec)
(Prior to S/N 76327)
Ref.
4/D
4933144
Without Interlock (Australian Spec)
(S/N 76372 to Present)
Ref.
E
LIGHTS ELECTRICAL DIAGRAM (OPTIONAL)
Ref.
0253821/1282038
Headlights and Taillights
Ref.
3/E
0253818/1282038
Headlights, Taillights, Brake Lights & Signal
Lights
Ref.
3/E
4932624
Panel Lights - Ground Control Box
Ref.
—
4932623
Panel Lights - Platform Console Box
Ref.
—
0253792/1282033
Platform Worklights with 2 Lights (25RTS)
Ref.
—/B
0253793/1282033
Platform Worklights with 2 Lights (33RTS)
Ref.
—/B
0253794/1282033
Platform Worklights with 2 Lights (40RTS)
Ref.
—/B
0257913
Platform Worklights with 4 Lights
Ref.
1
0253852
Platform Worklights with Cable Reels
Ref.
B
0253569
OIL COOLER ELECTRICAL DIAGRAM
Ref.
A
OVERLOAD PROTECTION INSTALLATION
(CE SPECS)
Ref.
0257772
Prior to S/N 83966
Ref.
A
0270785
S/N 83966 to Present
Ref.
E
PLATFORM ELECTRICAL DIAGRAMS
Ref.
4932602/1282009*
Deutz Engine Machines
(All Specs Prior to S/N 46645)
Ref.
B/N
4932602/1282009*
Deutz Engine Machines (CE Spec S/N46645 to
S/N 57701)
Ref.
B/N
4933095/1283063*
Deutz Engine Machines (CE Spec S/N 57701 to
Present)
Ref.
2/F
4933049/1282961*
Deutz Engine Machines
(Australian Spec S/N46645 to S/N 61097)
Ref.
1/F
4933094/1283061*
Deutz Engine Machines
(Australian Spec S/N 61097 to Present)
Ref.
3/H
4932602/1282008
Ford Engine Machines
(All Specs Prior to S/N46645)
Ref.
B/N
4932602/1282008
Ford Engine Machines
(CE Spec S/N46645 to S/N 57701)
Ref.
B/N
4933095/1283062
Ford Engine Machines
(CE Spec S/N 57701 to Present)
Ref.
2/F
4933049/1282960
Ford Engine Machines
(Australian Spec S/N46645 to S/N 61097)
Ref.
1/A
4933094/1283061
Ford Engine Machines
(Australian Spec S/N 61097 to Present)
Ref.
3/H
3990010
Diode - 6 Amp
6
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
