JLG 40RTS Parts Manual User Manual
Page 107
3120827
2-59
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
SECTION 2 GROUND COMPONENTS
50
Relay Options:
A/R
Not Required
Deutz Engine Machines (Prior to April 1993)
0
3740077
Deutz Engine Machines (April 1993 to Present)
1
Not Required
Ford Engine Machines
0
51
Breaker, Circuit - 10 Amp Options:
A/R
Not Required
Deutz Engine Machines (Prior to S/N 30660)
0
4360069
Deutz Engine Machines (S/N 30660 to Present)
2
Not Required
Ford Engine Machines
0
52
Nut, Seal Options:
A/R
Not Required
Deutz Engine Machines (Prior to S/N 30660)
0
3300396
Deutz Engine Machines (S/N 30660 to Present)
2
Not Required
Ford Engine Machines
0
53
Bar, Buss - 2 Position Options:
A/R
Not Required
Deutz Engine Machines (Prior to S/N 30660)
0
4460308
Deutz Engine Machines (S/N 30660 to Present)
1
Not Required
Ford Engine Machines
0
54
Washer, Bronze Options:
A/R
Not Required
Prior to S/N37155
0
4740066
S/N37155 to Present
1
55
4070987
Shim, Nylon (S/N 65031 to Present)
5
56
3910804
Screw #8-32 NC x 1/4” (S/N 65031 to Present)
6
57
0641406
Bolt 1/4”-20NC x 3/4” (S/N 70902 to Present)
A/R
58
0721004
Bolt #10-24NC x 1/2” (S/N 70902 to Present)
3
59
0720603
Bolt #6-32NC x 3/8” (S/N 70902 to Present)
4
60
0641408
Bolt 1/4”-20NC x 1”
1
61
0721006
Bolt #10-24NC x 3/4”
1
62
4751000
Flatwasher #10
1
63
3340841
Pad, PVC (Not Shown)
4
64
2420084
Light Kit, Gauge (Not Shown)
3
65
3790012
O-Ring (Not Shown)
1
GROUND CONTROL BOX INSTALLATIONS
Ref.
0253722
All Deutz Powered Machines (Prior To April 1993)
Ref.
—
0254108
All Deutz Powered Machines (April 1993 To
S/N 50053)
Ref.
B
0254108
CE Spec Deutz Powered Machines (S/N 50053 To
Present)
Ref.
B
0258639
Australian Spec Deutz Powered Machines
(S/N 50053 to Present)
Ref.
1
0253721
All Ford Powered Machines (Prior To April 1993)
Ref.
—
0254107
All Ford Powered Machines (April 1993 To Pres-
ent)
Ref.
B
101
Not Used
102
0641410
Bolt 1/4"-20NC x 1 1/4" (Standard)
2
103
4751400
Flatwasher 1/4"
4
104
4761400
Lockwasher 1/4"
2
105
3311401
Nut 1/4"-20NC
2
106
0362591
Bar, Brace
1
FIGURE 2-13. GROUND CONTROL BOX INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
