JLG 40RTS Parts Manual - Manual (Page 87)

3120827 2-39
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
SECTION 2 GROUND COMPONENTS
FIGURE 2-9. ENGINE INSTALLATION - DEUTZ F2L1011
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
ENGINE INSTALLATION OPTIONS: Ref.
0253361 EN280 And Australian Spec Ref. 18
0257246 CE Spec Ref. 10
1 Engine Options - Deutz F2L1011: 1
2000106 Prior to August 1995
2000137 August 1995 to Present
2 4843934 Tray, Engine Mounting 1
3 Not Used
4 Pump Assembly Options - Sunstrand (See Figure
2-11 for Breakdown): 1
3600164 13 Tooth Spline (Prior to S/N 30660)
3600260 15 Tooth Spline (S/N 30660 to Present)
5 0361817 Spacer, Engine Mounting 4
6 0080177 Adapter, Air Intake 1
7 Adapter, Throttle Options: 1
0080172 Prior to August 1995
4460302 August 1995 to Present
8 3450202 Pin, Cotter 1/16" x 1/2" 1
9 3951003 Setscrew #10-24NC x 3/8" (Prior to August 1995) 1
0902244 Bracket, Throttle (August 1995 to Present) 1
10 0641840 Bolt 1/2"-13NC x 5" 4
11 3311805 Locknut 1/2"-13NC 4
12 4751800 Flatwasher 1/2" 4
13 0641406 Bolt 1/4"-20NC x 3/4" A/R
14 4711400 Lockwasher 1/4" A/R
15 3311405 Locknut 1/4"-20NC A/R
16 0641512 Bolt 3
17 Cable, Battery Options: 1
1060406 Prior to S/N 70832
1060254 S/N 70832 to Present
18 1060093 Cable, Battery 1
19 0140001 Horn 1
20 0641610 Bolt 3/8"-16NC x 1 1/4" 2
21 4751600 Flatwasher 3/8" 18
22 0060023 Actuator, Throttle 1
7008828 Cable, Throttle 1
23 0901817 Bracket, Fuel Filter 1
24 0701010 Bolt, Metric M10 x 20mm 4
25 4832000 Lockwasher 10m 4
26 0641508 Bolt 5/16"-18NC x 1" 2
27 3311501 Nut 5/16"-18NC 5
28 4761500 Lockwasher 5/16" 5
29 4751600 Lockwasher 3/8" 12
30 0400003 Battery (Prior to S/N44593) 1
0400075 Battery (S/N44593 to Present) 1
31 0400002 Tie-Down, Battery (Prior to S/N44593) 1
0400174 Tie-Down, Battery (S/N44593 to Present) 1
