SECTION 6 - JLG CONTROL SYSTEM (S/N 0300065534 TO PRESENT)
3120858 – JLG Lift – 6-51
BASKET UP OVERRIDE OPEN CIR-
CUIT Only occurs on machines with electronic leveling systems.
BASKET UP OVERRIDE SHORT TO
BATTERY Only occurs on machines with electronic leveling systems.
BASKET UP SHORT TO GROUND
BASKET UP OPEN CIRCUIT
BASKET UP SHORT TO BATTERY
BASKET DOWN SHORT TO
GROUND
BASKET DOWN OPEN CIRCUIT
BASKET DOWN SHORT TO BAT-
TERY
BASKET DOWN OVERRIDE SHORT
TO GROUND
Only occurs on machines with electronic leveling systems.
BASKET DOWN OVERRIDE OPEN
CIRCUIT Only occurs on machines with electronic leveling systems.
BASKET DOWN OVERRIDE SHORT
TO BATTERY Only occurs on machines with electronic leveling systems.
BASKET LEFT OPEN CIRCUIT
BASKET LEFT SHORT TO BATTERY
BASKET LEFT SHORT TO GROUND
BASKET RIGHT SHORT TO
GROUND
BASKET RIGHT OPEN CIRCUIT
BASKET RIGHT SHORT TO BAT-
TERY
JIB UP SHORT TO GROUND
JIB UP OPEN CIRCUIT
JIB UP SHORT TO BATTERY
JIB DOWN SHORT TO GROUND
JIB DOWN OPEN CIRCUIT
JIB DOWN SHORT TO BATTERY
JIB LEFT SHORT TO GROUND
JIB LEFT OPEN CIRCUIT
JIB LEFT SHORT TO BATTERY
JIB RIGHT SHORT TO GROUND
JIB RIGHT OPEN CIRCUIT
JIB RIGHT SHORT TO BATTERY
TOWER UP SHORT TO GROUND
TOWER UP OPEN CIRCUIT
TOWER UP SHORT TO BATTERY
TOWER DOWN SHORT TO GROUND
TOWER DOWN OPEN CIRCUIT
Table 6-8. Help Fault Codes, Displayed Faults, and Descriptions - S/N 0300066931 to Present
Fault Flash
Code
Communicated (Displayed on
Analyzer) Fault
Description Priority
