SECTION 5 - HYDRAULICS
3120858 – JLG Lift – 5-11
5
1
19
19
26
21
12
13
6
30
18
16
11
11
10
17
16
4
22
31
3
24
19
19
2
8
7
15
14
1683547 J
1. Barrel
2. Rod
3. Piston
4. Tapered Bushing
5. O-ring Plug
6. Head
7. Ring Washer 8. Bolt
9. Not Used
10. O-ring
11. Backup Ring
12. Wiper
13. Rod Seal 14. O-ring
15. Backup Ring
16. Wear Ring
17. T-Seal
18. Seal
19. Bushing 20. Not Used
21. Valve Cartridge
22. Orifice
23. Loctite #242
24. Check Valve
25. Locking Primer 26. Plug
27. Not Used
28. Not Used
29. Loctite RC609
30. Wear RIng
31. Bolt
Figure 5-6. Main Boom Lift Cylinder
