SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

3121636

– JLG Lift –

6-29

CURRENT A

2,5

Indicates (in tenth of mA) the current ECM1-2 is sending to the aerial part

proportional valve or to the left-side undercarriage proportional valve (values less

that 5 not relevant)

CURRENT B

45,3

Indicates (in tenth of mA) the current ECM1-2 is sending to the right-side

undercarriage proportional valve (values less that 5 not relevant)

CURRENT C

Do not consider

TEMPERAT.

37,6

Indicates the temperature of the control module in C°

SUPPLY (V)

12,1

Indicates the batteries voltage, or the output voltage from the battery charger

BATTERY %

100

Only for Lithium version: indicates the % level of charge of the pack
