SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
3121322 – JLG Lift – 6-33
NOTE: Position 1 = Termination point in the Main Terminal Box (There are 4 connections at each terminal position on X1.
These are designated as 4 = Top Top, 3 = Tob Bottom, 2 = Bottom Top, and 1 = Bottom Bottom.) Position 2 = The posi-
tion on the end item (if not specified in the table, it can be located on the electrical schematic).
ader 4 X2/4 C2 J2A/4
ader 5 X2/5 C2 J2A/5
ader 6 X2/6 NC
ader 7 X2/7 NC
ader 8 X2/8 C2 J2A/8
ader 9 X2/9 trig contr J2/2
ader 10 X2/10 C2 J2B/2
ader 11 X2/11 NC
ader 12 X2/12 C2 J2B/4
ader 13 X2/13 C2 J2B/5
ader 14 X2/14 C2 J2B/6
ader 15 X2/15 C2 J2B/7
ader 16 X2/16 KTC/21
ader 17 X2/17 X1/59-1
ader 18 X2/18 C2 LED/YELLOW
ader 19 X2/19 KL/21
ader 20 X2/20 C2 LED/BLUE
ader 21 X2/21 NC
ader 22 X2/22 C2 LED/BLACK
ader 23 X2/23 X1/58-1
ader 24 X2/24 NC
GGN NC NC
D1 DIO BY550 X1/7-3 X1/8-3
D18 DIO BY550 K TC/A2 K TC/A1
D23 DIO BY550 KL/A2 KL/A1
D2 398 ANSI DIO X1/8-4 X1/33-3
D3 398 ANSI DIO X1/11-4 X1/41A-3
D4 398 ANSI DIO X1/11-4 X1/40-3
D5 398 ANSI DIO X1/25-3 X1/B-3
D6 398 ANSI DIO X1/32-4 X1/B-4
D7 398 ANSI DIO X1/41B-4 X1/21-2
D8 398 ANSI DIO X1/20-3 X1/C-3
D9 398 ANSI DIO K VS/A1 K VS/A2
D10 398 ANSI DIO KT/12 KT/21
D11 398 ANSI DIO X41/B-2 X1/22-3
D12 398 ANSI DIO KD2/A1 KD2/A2
D21 398 ANSI DIO X1/51-3 X1/30-3
D22 398 ANSI DIO X1/56-2 X1/30-2
E900065 C
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Wire Type Position 1 Position 2 Label (External Harness)
