SECTION 5 - JLG CONTROL SYSTEM
3121322 – JLG Lift – 5-3
Table 5-1. J1 Connector
J1 Connector
1 Drive
2 Drive Height LS
3 Lower
4 Ground
5 Lift
6 Joystick Analog Signal
7 Pump 1
8 Max Height L/S
9 Steer Right
10 Steer Left
11 Tilt Switch
12 Fast Drive
13 Fast Drive L/S
14 Not Used
15 Ignition
16 Pump 2
17 Start
18 Diff Lock
19 Platform In
20 Not Used
21 Ground
22 Platform Out
23 Horn
24 24V Power
Table 5-1 Key
= Output Signal
= Input Signal
= Not Used
Table 5-2. J2 Connector
J2 Connector
1 24V to Console
2 Deck Extension
3 Ignition
4 Start
5 Horn
6 Not Used
7 Not Used
8 Differential Lock
9 Trigger Switch
10 Ground
11 Not Used
12 Steer Right
13 Lift Select
14 Steer Left
15 Fast Drive
16 Joystick Analog Signal
Table 5-2 Key
= Output Signal
= Input Signal
= Not Used
Table 5-3. J3 Connector
J3 Connector
1 Not Used
2 Fast Drive LED
3 Max Height LED
4 Drive Height LED
5 Not Used
6 Ground
Table 5-3 Key
= Output Signal
= Input Signal
= Not Used
