SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
6-32 – JLG Lift – 3121322
ader 1 J7/1 1 OUTRIGGER 1 VALVE
ader 2 J7/2 2
ader 3 J7/3 PE
ader 4 J7/4 1 OUTRIGGER 2 VALVE
ader 5 J7/5 2
ader 6 J7/6 PE
ader 7 J7/7 1 OUTRIGGER 3 VALVE
ader 8 J7/8 2
ader 9 J7/9 PE
ader 10 J7/10 1 OUTRIGGER 4 VALVE
ader 11 J7/11 2
GGN J7/12 PE
126 LIYYJZ25X0,75UL GROUND PANEL
ader 1 X1/1-1 PA
ader 2 X1/2-1 PB
ader 3 X1/3-1 PC
ader 4 X1/4-2 PD
ader 5 X1/5-1 PE
ader 6 X1/6-1 PF
ader 7 X1/7-1 PG
ader 8 X1/9-2 PH
ader 9 X1/21-2 PJ
ader 10 X1/22-2 PK
ader 11 X1/56-1 PL
ader 12 X1/38-4 PM
ader 13 X1/41A-4 PN
ader 14 X1/32A-4 PO
ader 15 X1/30-2 PP
ader 16 X1/42-1 PQ
ader 17 X1/43-1 PR
ader 18 X1/58-4 PS
ader 19 X1/A-1 PT
ader 20 D25/A PU
ader 21 X1/B34-1 PV
ader 22 NC PW
ader 23 NC PX
ader 24
GGN
110 LIYYJZ25X1 UL Scissors Cable Socket
ader 1 X2/1 C2 J2A/1
ader 2 X2/2 C2 J2A/2
ader 3 X2/3 C2 J2A/3
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Wire Type Position 1 Position 2 Label (External Harness)
