SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
6-30 – JLG Lift – 3121322
ader 1 X1/39-1
ader 2 X1/44-2
ader 3 X1/43-2
ader 4 X1/48-2
GGN
88 LIYYJZ2X1 UL DOWN SWITCH
ader 1 X1/32A-2
ader 2 X1/55-1
90 LIYYJZ2X1 UL PUMP 2 VALVE
ader 1 X1/24-1 1
ader 2 X1/H-3 2
91 LIYYJZ2X1 UL PUMP 1 VALVE
ader 1 X1/11-1 1
ader 2 X1/G-1 2
93 LIYYJZ4X0,75 UL TILT SWITCH
ader 1 X1/28-1
ader 2 X1/29-1
ader 3 X1/B-2
GGN
95 LIYYJZ2X1 UL PRESSURE NIVO SWITCH
ader 1 X1/53-1 1
ader 2 X1/54-1 2
96 LIYYJZ2X1 UL HORN
ader 1 X1/25-1
ader 2 X1/G-2
97 LIYYJZ2X1 UL S DRIVE HEIGHT
ader 1 X1/36-1
ader 2 X1/37-1
ader 3 X1/30-1
ader 4 D24/A
GGN
98 LIYYJZ2X1 UL LOWERING VALVE
ader 1 X1/32-1 Splice2/L S5
ader 2 X1/A-2 Splice3/L S5
112 LIYYJZ2X1 UL
ader 1 1 Splice2/R S5
ader 2 2 Splice3/R S5
113 LIYYJZ2X1 UL
ader 1 1 Splice2/R S5
ader 2 2 Splice3/R S5
99 LIYYJZ2X1 UL SER/PAR
ader 1 X1/16-1 1
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Wire Type Position 1 Position 2 Label (External Harness)
