SECTION 2 - TURNTABLE
3121182 510AJ 67
FIGURE 2-8. 2500W GENERATOR INSTALLATION - CATERPILLAR MACHINES (WITH UGM)
(OPTIONAL)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref Note: For Module (with/without UGM) Identification, refer to
Revision Log page A.
Ref GENERATOR INSTALLATION
1001111285 Ref 110V/60HZ GENERATOR A
1001100944 Ref 110V/50Hz Generator B
1001100943 Ref 220V/50HZ GENERATOR B
Ref Note: Refer to Sky Power Accessories Manual p/n 3124242 for
the Miller 7500W Generator.
1 0100011 AR Compound, Locking
2 0200742 1 Arm, Adjusting
3 Ref V-Belt Options:
3 0480121 1 110V/60Hz
3 0480120 1 110V/50Hz
3 0480120 1 220V/50Hz
4 0641404 1 Bolt 1/4in-20NC x 1/2in
5 0641508 1 Bolt 5/16in-18NC x 1in
6 0641772 1 Bolt 7/16in-14NC x 9in
7 0701217 3 Bolt M12 x 45mm
8 0962449 1 Bushing
9 Ref Generator and Control Box Assembly Options:
9 2460055 1 110V/60Hz
9 2460049 1 110V/50Hz Generator
9 1001100321 1 220V/50Hz Generator
9A 7012558 1 Replacement Generator - 110V/60Hz
9A 2460049 1 Replacement Generator - 110V/50Hz
9A 1001100321 1 Replacement Generator - 220V/50Hz
Ref Note: All Replacement Generators come standard with P/N
3580134 Pulley. This Pulley may not be correct for all
applications. Refer to Pulley options below.
9A 7026199 1 110V/60Hz Armature with Slip Rings
9A 70000122 1 110V/50Hz Armature with Slip Rings
9A 70000123 1 220V/50Hz Armature with Slip Rings
9A 7020109 4 Holder, Brush
9A 7020108 4 Brush
9A 7012513 4 Cap, Brush Holder
9A 7012514 1 Fan
9A 7020190 2 Bearing
9A 7020110 1 End Bell, Front
9A 7020111 1 End Bell, Rear
9A 7020193 1 Cord, Power
9B Ref Replacement Control Box Options:
9B 7019680 1 110V
9B 70000127 1 220V
9B Ref Circuit Breaker Options:
9B 4360542 1 110V
9B 70000126 1 220V
9B 4460190 1 Receptacle, Double (110V Box)
9B 4460027 1 Receptacle, Double Twist Lock (110V Box)
9B 70000124 1 Receptacle, Double (220V Box)
9B 70000125 1 Receptacle, Single Twist Lock (220V Box)
