SECTION 2 - TURNTABLE
60 510AJ 3121182
FIGURE 2-7. CATERPILLAR ENGINE INSTALLATION (WITH UGM)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref Belgium Built Machines use SNs 13xxxxxxxx. Romanian Built
Machines use SNs E3xxxxxxxx.
Ref Note: For Module (with/without UGM) Identification, refer to
Revision Log page A.
1001108389 Ref CATERPILLAR ENGINE ASSEMBLY D
1 0080181 1 Adapter, Pump Mounting Plate
2 0080201 1 Adapter, Elbow Air Intake
3 0100011 AR Compound, Locking
4 0641812 2 Bolt 1/2in-13NC x 1-1/2in
5 0340041 2 Band, Air Cleaner Mounting
6 0340046 2 Band, Muffler Mounting
7 2111010 1 Fitting, Straight
8 2111612 1 Fitting, Straight
9 0630569 9 Bolt M14 x 30mm
10 0641406 8 Bolt 1/4in-20NC x 3/4in
11 0641408 3 Bolt 1/4in-20NC x 1in
12 0641410 2 Bolt 1/4in-20NC x 1-1/4in
13 0641506 8 Bolt 5/16in-18NC x 3/4in
14 0641507 6 Bolt 5/16in-18NC x 7/8in
15 0641609 5 Bolt 3/8in-16NC x 1-1/8in
16 0641610 39 Bolt 3/8in-16NC x 1-1/4in
17 0641611 2 Bolt 3/8in-16NC x 1-3/8in
18 0641614 2 Bolt 3/8in-16NC x 1-3/4in
19 0641820 4 Bolt 1/2in-13NC x 2-1/2in
20 0741610 2 Screw, Flat Head 3/8in-16NC x 1-1/4in
21 0760815 4 Bolt M8 x 35mm
22 0962172 1 Bushing, Flanged
23 1320012 4 Clamp
24 1320016 4 Clamp
25 1320022 3 Clamp
26 1320058 1 Clamp
27 1320223 6 Clamp
28 1320318 2 P-Clamp
29 1340060 1 Air Cleaner Assembly
29 7012664 1 Element, Air Cleaner
30 1580011 1 Container, Coolant Overflow
31 1660255 1 Coupling, Pump
32 1703162 2 Decal - Caution Fan
33 2131212 1 Fitting, Elbow
34 2720058 2.5
ft/0.8m
Hose
35 1001106426 1 Caterpillar Engine Assembly (See Items 301-321 for Breakdown)
36 3200378 4 Mount, Motor
37 Ref Muffler Options:
37 3220113 1 Spark Arresting Muffler
37 70001017 1 Clamp
37 1001107116 1 Catalytic Muffler
37 70002705 1 Clamp
37 70002706 1 Plug, Brass
38 3311405 11 Locknut 1/4in-20NC
