SECTION 5 - CYLINDER

3121182

510AJ

203

FIGURE 5-7. MASTER CYLINDER ASSEMBLY

ITEM

PART NUMBER

QTY

DESCRIPTION

REV

1684241

Ref

MASTER CYLINDER ASSEMBLY

C

1

7026085

1

Barrel

2

7026086

1

Rod

4

7026081

1

Piston

5

7026082

1

Head

8

0961951

4

Bearing

9

7026087

1

Seal

10

7026087

1

O-Ring

12

7026087

1

O-Ring

13

7026087

1

Ring, Back-up

14

7026087

1

Seal

15

7026087

1

Wiper

18

7026087

1

O-Ring

19

70002216

1

Ring, Retaining

21

7026087

1

O-Ring

23

70002217

1

Ring, Retaining

25

7026087

1

Seal Kit, Cylinder (Includes Items 9, 10, 12-15, 18 & 21)
