SECTION 6 - HYDRAULIC
3121182
510AJ
221
FIGURE 6-5. DRIVE HYDRAULIC DIAGRAM (BELGIUM BUILT MACHINES AND ROMANIAN BUILT
MACHINES) (SN 1300003476 to Present, SN E300000100 through E300001114)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
Belgium Built Machines use SNs 13xxxxxxxx.
Ref
Romanian Built Machines uses SNs E3xxxxxxxx.
1001094635
Ref
DRIVE HYDRAULIC DIAGRAM - 4WD
3
1
2110406
2
Fitting, Straight
2
2110808
10
Fitting, Straight
3
2110812
8
Fitting, Straight
4
2130406
2
Fitting, Elbow
5
2130808
6
Fitting, Elbow
6
2221088
1
Fitting, Tee
7
2170504
4
Fitting, Tee
8
2130812
1
Fitting, Elbow
9
2110604
2
Fitting, Straight
10
2130404
3
Fitting, Elbow
11
2221085
2
Fitting, Elbow
12
2131008
1
Fitting, Elbow
13
2111620
1
Fitting, Straight
14
2753546
2
Hose
15
2753537
2
Hose
16
2753540
2
Hose
17
2753541
3
Hose
18
2753586
2
Hose
19
2753580
1
Hose
20
2753581
1
Hose
21
2754244
4
Hose
22
1001094649
4
Hose
23
2753605
1
Hose
25
2753843
1
Hose
26
2753594
1
Hose
27
2753595
1
Hose
28
2753588
1
Hose
29
2753604
2
Hose
30
2753538
1
Hose
31
2753578
1
Hose
32
2753610
1
Hose
33
2221216
1
Fitting, Straight
34
2221183
1
Fitting, Straight
35
2110404
1
Fitting, Straight
36
2753787
1
Hose
37
2753602
1
Hose
38
2754471
1
Hose
39
2131216
1
Fitting, Elbow
40
2221296
1
Fitting, Straight
41
2170512
1
Fitting, Tee
42
2753698
1
Hose
44
2111212
2
Fitting, Straight
45
4641281
1
Valve, Check
