SECTION 2 - TURNTABLE
3121182 510AJ 43
FIGURE 2-1. CONTROL VALVE INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
Ref VALVES INSTALLATIONS
0271197 Ref Belgium Built Machines (Prior to SN 1300001243) F
0274616 Ref Belgium Built Machines (SN 1300001243 to Present) A
0274616 Ref Romanian Built Machines (SN E300000100 through
E300001114) A
1 0100011 AR Compound, Locking
2 0140001 1 Horn
4 0641404 1 Bolt 1/4in-20NC x 1/2in
5 0651405 4 Bolt 1/4in-24NF x 5/8in
7 0641607 4 Bolt 3/8in-16NC x 7/8in
9 Ref Pressure Filter Assembly Options:
9 2120163 1 Belgium Built Machines (Prior to SN 1300001243)
9 2120150 1 Element, Filter
9 7020020 1 Indicator
9 7023206 1 O-Ring, Filter
9 7023207 1 Ring, Back-up
9 2120209 1 Belgium Built Machines (SN 1300001243 to Present)
9 2120209 1 Romanian Built Machines (SN E300000100 through
E300001114)
9 2120210 1 Element, Filter
9 7020020 1 Indicator
9 70000934 1 O-Ring, Filter Bowl
11 4641176 1 Main Control Valve Assembly (See MAIN CONTROL VALVE
ASSEMBLY for Breakdown)
14 4711600 10 Flatwasher 3/8in Thin
15 4751400 1 Flatwasher 1/4in Regular
20 4711400 4 Flatwasher 1/4in Thin
21 4791400 1 Starwasher 1/4in
