SECTION 4 - PLATFORM
3121182 510AJ 187
FIGURE 4-5. SOFT TOUCH SYSTEM INSTALLATION (OPTIONAL)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref Note: No Longer Available. Parts below are for Service Only.
Ref SOFT TOUCH SYSTEM INSTALLATION
0274240 Ref 6ft/8m Platform C
1 0100011 AR Compound, Locking
2 0200048 2 Arm, Switch Activator
3 0630462 8 Bolt, Carriage
4 0641414 8 Bolt 1/4in-20NC x 1-3/4in
5 0731005 4 Screw #10-32NF x 5/8in
6 0940167 Kit, Bumper Soft Touch
7 1060341 15 ft/4.6m Cable, Control - 16/2
8 1060903 4 Wire Rope and Eyebolt Assembly
9 1702938 1 Decal, Soft Touch Override
10 3311401 8 Nut 1/4in-20NC
11 3311501 8 Nut 5/16in-18NC
12 3575705 2 Plate, Switch Strike
13 4240099 1 Tie, Wire (Not Shown)
14 4360057 2 Switch, Limit
15 4360387 1 Switch, Yellow Push Button
16 4420068 1 Tape, Yellow Adhesive
17 4460049 2 Connector, Strain Relief
18 4460234 2 Terminal, Mount Cable Tie (Not Shown)
19 4460425 1 Terminal, Strain Relief (Not Shown)
20 4751400 16 Flatwasher 1/4in Regular
21 4751500 8 Flatwasher 5/16in Regular
22 4751800 8 Flatwasher 1/2in Regular
23 4846370 1 Weldment, Soft Touch Rail
25 2920028 1 Lamp, Indicator (SN 1300006701 to Present)
26 2920029 1 Bulb, Light (SN 1300006701 to Present)
