SECTION 2 - TURNTABLE
48 510AJ 3121182
ITEM PART NUMBER QTY DESCRIPTION REV
111 3311605 2 Locknut 3/8in-16NC
112 4751600 4 Flatwasher 3/8in Regular
1001102695 Ref DRIVE ORIENTATION INSTALLATION (BELGIUM BUILT
MACHINES) (SN 1300006701 to Present) D
1001102695 Ref DRIVE ORIENTATION INSTALLATION (ROMANIAN BUILT
MACHINES) (SN E300000100 through E300001114) D
201 0100011 AR Compound, Locking
202 0641406 1 Bolt 1/4in-20NC x 3/4in
203 0641606 2 Bolt 3/8in-16NC x 3/4in
204 0641614 2 Bolt 3/8in-16NC x 1-3/4in
205 1320041 1 Clamp
206 3311005 2 Locknut #10
207 3311405 1 Locknut 1/4in
208 3931010 2 Screw #10-24 x 5/8in
209 4360517 1 Switch, Proximity
209 4460320 1 Connector, Male
209 4460227 2 Pin, Male
210 4711000 2 Flatwasher #10 Thin
211 4711400 1 Flatwasher 1/4in Thin
212 4711600 4 Flatwasher 3/8in Thin
213 1001145163 2 Spacer (was p/n 7116691 & 1001114757)
214 1001102526 1 Cam
215 1001102527 1 Bracket, Switch
216 4740120 2 Flatwasher, Special
