SECTION 2 - TURNTABLE

3121182

510AJ

119

ITEM

PART NUMBER

QTY

DESCRIPTION

REV

76

7024804

1

(3600385 Pump Only)

77

7021280

1

Nut, Seal

78

7022386

1

Swashplate

79

7022387

1

Slider, Block

80

7021294

1

Coupling

81

7001481

2

Pin

82

70002257

1

Gasket

83

7021296

7

Screw

84

7021297

1

Cover, Charge Pump

85

7021298

1

Seal

86

7021299

1

Plate, Cover

87

7007289

2

Screw

88

7007470

1

Plug (Not Shown) (3600385 Pump Only)

89

7021256

1

O-Ring (Not Shown) (3600385 Pump Only)

95

7021280

Seal Kit (Includes Items 5-6, 22, 26, 30, 32, 42, 47-49, 53, 68-70,
73, 77, 82 & 89)
