EASI-CLADDER™ PLUS
3128112 – JLG Accessory Manual – 45
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Figure 19. EASI-CLADDER PLUS ELECTRICAL PARTS COMPONENTS Ref.
0273061 ELECTRICAL MODULE AND HARNESS INSTALLATION Ref. C
1 0641406 Bolt 1/4"-20NC x 3/4" 4
2 to 5 Not Used
6 1600356 Module, Controller 1
7 3311405 Locknut 1/4"-20NC 4
8 to 11 Not Used
12 4922919 Arms Harness (Left Side) 1 C
12A 4460502 Receptacle, Female - 31 Position 1
4460466 Plug, Sealing 7
4460465 Socket, Female 24
4460473 Clamp, Terminal 1
12B 4460836 Plug, Male - 12 Position (Black) 1
4460466 Plug, Sealing 4
4460465 Socket, Female 8
0840055 Boot 1
12C 4460933 Plug, Male - 12 Position (Gray) 1
4460466 Plug, Sealing 3
4460465 Socket, Female 9
0840055 Boot 1
12D 4460934 Plug, Male - 12 Position (Green) 1
4460466 Plug, Sealing 6
4460465 Socket, Female 6
0840055 Boot 1
12E 4460935 Plug, Male - 12 Position (Brown) 1
4460466 Plug, Sealing 3
4460465 Socket, Female 9
0840055 Boot 1
12F 4460930 Plug, Male - 8 Position 1
4460466 Plug, Sealing 3
4460465 Socket, Female 5
0840058 Boot 1
12G 4460499 Connector, DIN 6
12H 4460891 Plug, Male - 2 Position 1
4460465 Socket, Female 2
12J 4460536 Receptacle, Female - 3 Position 1
4460464 Pin, Male 3
12K 0861609 Box, Control 1
1705757 Decal, Front 1
12L 2920108 Bulb, Light 1
2920141 Lamp, Indicator 1
12M 4060906 Guard, Switch 5
4360328 Switch, Toggle 4
4360555 Switch, Toggle - Leverlock 1
12N 4460071 Connector, Strain
12P 4460259 Terminal 19
4460260 Housing, Terminal 19
