EASI-CLADDER™ PLUS
3128112
– JLG Accessory Manual –
31
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
Figure 13.
0273303
EASI-CLADDER PLUS VACUUM ARMS PARTS COMPONENTS
Ref.
2
0273043
Vacuum Arms Assembly
Ref.
E
1 to 2
Not Used
3
0641406
Bolt 1/4"-20NC x 3/4"
4
4
0641420
Bolt 1/4"-20NC x 2 1/2"
4
5
0641514
Bolt 5/16"-18NC x 1 3/4"
8
6
0691810
Bolt 1/2"-24NF x 1 1/4""
4
7
0721014
Screw #10-24 x 1 3/4"
2
8
0641604
Bolt 3/8"-16NC x 1/2"
2
9
1600356
Module, Controller
1
10 to 12
Not Used
13
3311005
Nut #10-24NC
2
14
3311405
Locknut 1/4"-20NC
4
15
3311505
Locknut 5/16"-18NC
8
16
3340973
Pad, Suction
12
1671129
Cover, Vacuum Cup
2
17
3574393
Plate, Cam
2
18
3600380
Pump, Vacuum
1
19 to 20
Not Used
21
3930828
Capscrew #8-32 x 1 3/4"
4
22
0641812
Bolt 1/2"-13NC x 1 1/2""
1
23
Not Used
24
4641277
Valve, Orifice
2
25
4641279
Valve, Manual
1
26
Not Used
27
4751000
Flatwasher #10
4
28
4751500
Flatwasher 5/16"
4
29
4846845
Reservoir, Vacuum
2
30
4891800
Flatwasher 1/2" Hardened
4
31
4922928
Relay Harness
1
32
4922934
Limit Switch Harness (S/N 115825 to Present)
2
Use 4360549
Limit Switch (1 per Harness) (was p/n 4360322)
1
4460968
Connector, Strain Relief (1 per Harness)
1
4460464
Pin, Male (2 per Harness)
2
4460897
Terminal, 2 Position Receptacle (1 per Harness)
1
33
3311805
Locknut 1/2"-13NC (S/N 115825 to Present)
1
34
3340852
Pad, Wear (S/N 115825 to Present)
1
35
3574620
Plate, Vacuum Pump Mounting (S/N 115825 to Present)
1
36
4711800
Flatwasher 1/2 (S/N 115825 to Present)
2
37
2120192
Filter, Water Separator (S/N 116736 to Present)
2
38
3380516
Panel, Cladder Valve Cover (S/N 116736 to Present)
2
39
4751400
Flatwasher 1/4" (S/N 116736 to Present)
8
40
0641414
Bolt 1/4"=20NC x 1 3/4" (S/N 116736 to Present)
4
