EASI-CLADDER™ PLUS
3128112 – JLG Accessory Manual – 29
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Figure 12. 0272957 CLADDER ASSEMBLY Ref. D
1 0641405 Bolt 1/4"-20NC x 5/8" 4
2 0641509 Bolt 5/16"-18NC x 1 1/8" 3
3 0641524 Bolt 5/16"-18NC x 3" 2
4 0641604 Bolt 3/8"-16NC x 1/2" 4
5 0641605 Bolt 3/8"-16NC x 5/8" 4
6 0641606 Bolt 3/8"-16NC x 3/4" 6
7 0641812 Bolt 1/2"-13NC x 1 1/2" 2
8 0641816 Bolt 1/2"-13NC x 2" 2
9 0962173 Bushing 4
10 0962528 Bushing, Spacer 4
11 Cylinder, Cladder Lift Options: 1
1684236 Prior to S/N 116093
1684352 S/N 116093 to Present
12 Cylinder, Cladder Telescope Options: 1
1684272 Prior to S/N 116093
1684353 S/N 116093 to Present
13 Cylinder, Cladder Manipulator Options: 1
1684279 Prior to S/N 116093
1684354 S/N 116093 to Present
14 3311505 Locknut 5/16"-18NC 5
15 3311602 Nut, Jam 3/8"-16NC 2
16 3311805 Locknut 1/2"-13NC 4
17 3340852 Pad, Wear 7
18 3340951 Pad (Front) 2
19 3422828 Pin 1
20 3422899 Pin 1
21 3423051 Pin 1
22 3423052 Pin 1
23 3423053 Pin 1
24 3423055 Pin 1
25 3574511 Plate, Cradle 1
26 3760351 Ring, Retaining 4
27 3841143 Keeper, Pin 3
28 3860083 Roller 6
29 3900289 Bolt, Shoulder 1/2"-13NC x 1" 2
30 3900273 Bolt, Shoulder 1/2"-13NC x 2" 4
31 4070904 Shim #16 Gauge A/R
32 4071065 Shim .125 4
33 4711500 Flatwasher 5/16" Narrow 4
34 4711600 Flatwasher 3/8" Narrow 8
35 4711800 Flatwasher 1/2" Narrow 20
36 4846830 Tube, Hat 1
37 4846831 Tube, Slide 1
38 4846833 Arm, Lift 1
39 4846883 Attach, Pivot 1
