EASI-CLADDER™ PLUS
14 – JLG Accessory Manual – 3128112
DESCRIPTION
The cladding accessory when mounted to a scissor lift, is designed to lift
and position insulated wall panels for attachment to a structure on the con-
struction site. The main components are two panel loading frames with tele-
scoping/lifting panel handling arms installed on the scissor deck. The
frames are bolted to the scissor lift deck and are stabilized by C-shaped
brackets attaching them to the vertical posts of the scissor lift platforms’
handrail system.
The cladding accessory can be removed from the scissor lift deck when not
required on the job site. All electrical, hydraulic, and vacuum lines to the
cladding accessory are attached under the scissor deck using quick cou-
plers for easy disconnect.
SPECIFICATION
Table 3. - Platform: Ratings
3394RT
(7.25m - Dual Extension Decks Only)
500RTS
(with MegaDeck Only)
500RTS
(with Dual Extension Decks Only)
Max. Capacity
Persons 2 2 2
Wind 12.5 m/s 12.5 m/s 12.5 m/s
Outriggers Required Required Required
Max. Platform
Capacity *
905kg - 385kg = 520kg 680kg - 385kg = 295kg 900kg - 385kg = 515kg
* Derated 385kg (850lb.) due to weight of cladding accessory mounted on platform deck.
Table 4. - Cladding Accessory Specifications
Requirement/Function
3394RT
(7.25m - Dual Extension Decks)
500RTS
(with MegaDeck)
500RTS
(with Dual Extension Decks)
Cladding Panel
Max. Panel Length 8m 8m 8m
Max. Panel Width 1.30m 1.30m 1.30m
Maximum Panel Weight 250kg 125kg 250kg
Max. Surface Irregularity
(for vacuum to hold) Panel must be smooth and free of high ridges in the area where the vacuum cups attach to
the panel surface. The GREEN vacuum indicator light on the control box must be lit before
panel can be lifted upright 90° for installation.
Hydraulic Power Requirements
Pressure 3000psi 3000psi 3000psi
Flow 2gpm 2gpm 2gpm
Control Functions Tether Control Box Tether Control Box Tether Control Box
Deck Extension Dual, Powered Dual, Powered Dual, Powered
Electric Power Requirements for Vacuum Pump
Vacuum Pump 110 volt - 50Hz - 1 Phase - Minimum Vacuum Required 24.0 –in. Hg
Onboard Electric
Generator 110 volt -
2800 Watt (Continuous)
110 volt -
2500 Watt (Continuous)
