EASI-CLADDER™ PLUS
3128112 – JLG Accessory Manual – 43
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Figure 18. EASI-CLADDER PLUS BULKHEAD & VACUUM SWITCH PARTS
COMPONENTS (VACUUM ARMS ONLY) Ref.
0273271 BULKHEAD PLATE & VACUUM SWITCH VALVE INSTALLATION -
3394RT & 4394RT Ref. C
1 3311605 Locknut 3/8"-16NC 4
2 3573854 Plate, Bulkhead 2
3 3900316 Screw 3/8"-16NC x 1" 4
4 4360547 Switch, Vacuum 1
5 4460470 Terminal, Nut (S/N 115825 to Present) 2
6 4460471 Terminal, Lockwasher (S/N 115825 to Present) 2
0273302 BULKHEAD PLATE & VACUUM SWITCH VALVE INSTALLATION -
500RTS Ref. D
101 0641526 Bolt 5/16"-18NC x 3 1/4" 2
102 0861635 Box, Junction 1
103 3310805 Locknut #8-32NC 4
104 3311605 Locknut 3/8"-16NC 7
105 3573854 Plate, Bulkhead 2
106 3900316 Screw 3/8"-16NC x 1" 7
107 3930816 Screw #8-32NC x 1" 4
108 4360547 Switch, Vacuum 1
109 4641295 Valve Assembly 1
110 4711500 Flatwasher 5/16" 4
111 4846674 Bracket 1
112 4460470 Terminal, Nut 2
113 4460471 Terminal, Lockwasher 2
114 1870171 Schematic, Electrical 1
115 3311505 Locknut 5/16"-18NC 2
