JLG Easi-Cladder - Manual (Page 17)

EASI-CLADDER™
3128112 – JLG Accessory Manual – 9
304 0861492 Box, Circuit Card (Prior to S/N 112230 Only) 1 A
305 Not Used
306 3311405 Locknut 1/4"-20NC 2
307 3311605 Locknut 3/8"-16NC 7
308 3900316 Screw, Button 3/8"-16NC x 1" 7
309
4360533
Pendant Control Box Assembly (Includes Electrical Cable) (Prior
to S/N 112230 Only) 1
310 4641249 Control Valve Assembly 1
311 4711400 Flatwasher 1/4" Narrow 2
312 4711500 Flatwasher 5/16" Narrow 2
313 4846674 Bracket 1
314 4846675 Bracket, Coupler 2
315 4922812 Harness, Wiring 1 3/C
4460880 Connector, DIN 3
4460930 Plug, Male - 8 Position 1
4460465 Socket, Female 15
4460909 Plug - 12 Position (Black) 1
4460908 Plug - 12 Position (Gray) 1
4460928 Socket, Female 11
4460761 Receptacle, Female - 4 Position 1
4460267 Pin, Male 4
4460851 Plug, Male - 8 Position 1
4460852 Connector - 8 Position Bussbar Jumper 1
4460536 Receptacle, Female - 3 Position (S/N 112230 to Present Only) 1
4460464 Pin, Male (S/N 112230 to Present Only) 3
0840058 Boot (S/N 112230 to Present Only) 1
316 1600348 Module (S/N 112230 to Present Only) 1
317 0861565 Pendant Control Box Assembly (S/N 112230 to Present Only) 1 A
4360532 Switch 1
317A 4460539 Plug, Male - 3 Position 1
4460465 Terminal 3
0272531 EASI-CLADDER™ CABLE INSTALLATION (500RTS ONLY) Ref. 1
401 1060330 Cable, Electrical - 16/3 110ft
4460043 Ring, Terminal 1
3990010 Diode, 6 Amp 2
0272528 DECAL INSTALLATION Ref. B
501 1705462 Decal, Easi-Cladder™ Capacity 4
502 1705532 Decal, Easi-Cladder™ 4
EASI-CLADDER™ KITS Ref.
Not Available 3394RT/4394RT Ref.
0272436 500RTS Ref. 1
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
