EASI-CLADDER™ PLUS
3128112 – JLG Accessory Manual – 25
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Figure 11. 0273304 EASI-CLADDER PLUS™ BASE INSTALLATION Ref. 1
0272962 Cladder Sub-Assembly Ref. D
1 0100081 Loctite #454 (Not Shown) A/R
2 0272962 Cladder Assembly (See Figure 2-8 for Breakdown) 2
3 0641506 Bolt 5/16"-18NC x 3/4" 8
4 0641508 Bolt 5/16"-18NC x 1" 12
5 0641510 Bolt 5/16"-18NC x 1 1/4" 12
6 0641518 Bolt 5/16"-18NC x 2 1/4" 38
7 0641528 Bolt 5/16"-18NC x 3 1/2" 8
8 1120555 Cap, Manual Storage (Prior to S/N 116736) 2
9 2560088 Handle 4
10 3311505 Locknut 5/16"-18NC 66
11 3340969 Pad, Slide 4
12 Pad, Panel Options: 2
3340970 Prior to S/N 115825
3340983 S/N 115825 to Present
13 3340971 Pad, Storage 2
14 3422369 Pin, Plunger (Prior to S/N 115825) 4
15 3460334 Tube, Manual Storage (Prior to S/N 116736) 1
16 3574325 Plate, Tooth 2
17 3900190 Bolt, Shoulder 2
18 3900289 Bolt, Shoulder 8
19 4711500 Flatwasher 5/16" Narrow 50
20 4761500 Lockwasher 5/16" 8
21 Stop, Rotating Options: 4
4846668 Prior to S/N 115825
4848837 S/N 115825 to Present
22 4846872 Bracket 2
23 4846828 Leg (Front) 2
24 4846829 Bracket 2
25 4846832 Handrail 2
26 4846835 Stand, Storage 2
27 4846836 Leg 2
28 4846837 Handle 2
29 4846838 Mount, Stabilizer 2
30 4846839 Tube, Rachet 2
31 4846840 Handle 1
32 4846841 Leg 1
33 1320059 Clamp (Prior to S/N 116736) 2
34 to 36 Not Used
37 3574631 Plate, Pad Mount (S/N 115825 to Present) 2
38 Not Used
39 4846947 Leg, Vacuum Pump Mount (S/N 115825 to Present) 1
40 4891600 Flatwasher 3/8" (S/N 115825 to Present) 2
41 4891800 Flatwasher 1/2" (S/N 115825 to Present) 4
