Page 80

3-8
3120738
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
30
Cable, Electrical - 18/2 Options:
1060680
Prior to S/N 50027
15ft/4.06m
1060680
S/N 50027 to Present
21ft/6.40m
31
1100105
Cam, Activator
1
32
1683603
Lift Cylinder Assembly (See Section 5 for Breakdown)
1
33
Nut Options:
2
3311005
Locknut #10-24NC (Prior to S/N 50027)
3310801
Nut #8-32NC (S/N 50027 to Present)
34
3311501
Nut 5/16”-18NC
4
35
Locknut Options:
8
3311505
Locknut 5/16”-18NC (Prior to S/N 50027)
3311605
Locknut 3/8”-16NC (S/N 50027 to Present)
36
Not Used
37
3422641
Pin, Pivot
2
38
3422642
Pin, Headed (Prior to S/N 50027)
2
39
Pin, Pivot Options:
6
3422644
Prior to S/N 50027
3422746
S/N 50027 to Present
40
Pin, Pivot Options:
14
3422663
Prior to S/N 50027
3422743
S/N 50027 to S/N 82160
3422882
S/N 82160 to Present
41
Pin, Pivot Options:
2
3422671
Prior to S/N 50027
3422742
S/N 50027 to S/N 82160
3422862
S/N 82160 to Present
42
Pin, Pivot Options:
2
3422725
Prior to S/N 50027
3422747
S/N 50027 to Present
43
Not Used
44
3450804
Pin, Cotter 1/4” x 1”
2
45
3760387
Ring, Retaining
8
46
3841344
Rod, Retaining
2
47
Roller Options:
2
3860078
Prior to S/N 82160
3860092
S/N 82160 to Present
48
Screw Options:
2
3931024
Screw, Socket Head #10-24NC x 1 1/2”
(Prior to S/N 50027)
3930820
Screw, Socket Head #8-32NC x 1 1/4”
(S/N 50027 to S/N 111642)
3900329
Screw, Socket Head #8-32NC x 1 1/2”
49
Switch, Limit Options:
1
4360401
Prior to S/N 50027
4360548
S/N 50027 to Present (was p/n 4360321)
50
4420062
Tape, UHMW
5in/12cm
51
Connector, Strain Relief Options:
2
Use 4460662
1/2” Pipe Threads (Was P/N 4460049)
4460662
1/2” Pipe Threads (Used on Limit Switch p/n 4360321)
FIGURE 3-2. SCISSOR ARMS INSTALLATION - 1932E2 (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
