JLG 3246E2 ANSI Parts Manual - Manual (Page 209)

3120738 8-13
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
FIGURE 8-3. DECALS INSTALLATION - 2032E2/2632E2/2646E2/3246E2 (COMMON)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
DECAL INSTALLATION (COMMON) OPTIONS: Ref.
0257784 2032E2 & 2646E2 Ref. 11
0271876 2632E2 Ref. C
0259110 3246E2 Ref. 9
1 0641405 Bolt 1/4”-20NC x 5/8” 2
2 0860520 Box, Manual Storage 1
3 1060279 Cable, Lanyard 1
4 3311405 Locknut 1/4”-20NC 4
5 4751400 Flatwasher 1/4” 4
6 1702153 Decal - Inspection 1
7 1702773 Decal - JLG (5in) 2
8 1703816 Decal - Danger/Warning 1
9 3251813 Decal - USA (Prior to S/N 111924) 1
10 Not Available Nameplate - Serial Number 1
11 Not Used
12 Decal - Capacity Options: 3
1703694 2032E2 & 2646E2
1703868 2632E2
1704201 3246E2
13 1703697 Decal - Safety Prop 2
14 Decal - Manual Options: 1
Use 1701509 Decal for 2032E2 / 2646E2 / 3246E2 (Prior to S/N
102826) (was p/n 1703788)
1701509 Decal for 2032E2 / 2646E2 / 3246E2 (S/N 102826
to Present)
1701509 Decal for 2632E2
15 1703811 Decal - Lifting Lug 4
16 1703812 Decal - Hydraulic Oil 1
17 1703814 Decal - Tie Down 4
18 1704277 Decal - Lanyard Attachment 2
19 1703817 Decal - Forklift 4
20 1703819 Decal - Directional Arrow 3
21 1703821 Decal - Control Box Location 1
22 Decal - Manual Descent Instructions Options: 1
1703822 2032E2 & 2646E2
Not Required 3246E2
23 Not Used
24 1703695 Decal - Legend 1
25 1703698 Decal - Towing/Winching/Tow Speed 1
26 Decal - Manual Descent Instructions Options: 1
1704420 2032E2 & 2632E2
1703703 2646E2 & 3246E2 Prior to S/N 69053
1704420 2646E2 & 3246E2 S/N 69053 to Present
27 1703706 Decal - Ground Control Operation 1
28 1703813 Decal - Warning Battery Ventilation 1
29 1703818 Decal - Warning 2
30 1703823 Decal - Danger Electrocution Hazard 2
