Page 54

2 -20
3120738
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
22
Switch, Key Options:
1
4360432
Switch Used Prior to S/N 69428
4360471
Switch Used S/N 69428 to Present
22A
Key, Replacement Options:
1
7016339
Key Used Prior to S/N 69428
2860030
Key Used S/N 69428 to Present
23
4751000
Flatwasher #10
2
24
4751400
Flatwasher 1/4”
6
25
4761400
Lockwasher 1/4”
4
26
4922032
Harness, Power
(Not Shown - See Section 7 for Breakdown)
1
27
4922033
Harness, Lift Switch Power
(Not Shown - See Section 7 for Breakdown)
1
28
Harness, Valves Options
(Not Shown - See Section 7 for Breakdown)
1
4922102
1532E2/1932E2
4922034
2032E2/2632E2/2646E2/3246E2
29
Harness, Ground Controls Options
(Not Shown - See Section 7 for Breakdown):
1
4922035
Standard Specs
4922331
Nikken/Taiyo Spec
30
4922144
Harness, Relays
(Not Shown - See Section 7 for Breakdown)
1
31
Use 0902615
Bracket 1532E2/1932E2 (Was 0902433)
1
Use 0902615
Bracket 2032E2/2632E2/2646E2/3246E2 (Was 4845664)
32
Harness, Charger Interlock
(Not Shown - See Section 7 for Breakdown)
A/R
Not Required
1532E2/1932E2/2032E2/2646E2/3246E2 w/o Charger
Interlock
1
4922198
1532E2/1932E2 with Charger Interlock
1
4922199
2032E2/2632E2/2646E2/3246E2 with Charger Interlock
1
33
3910804
Screw #6-32NC x 1/4” (S/N 69428 to Present Only)
6
34
Shim Options:
A/R
4070987
Shim (.015) (S/N 69428 to S/N 85982 Only)
5
4071006
Shim (0.090) (S/N 85982 to Present Only)
1
35
Harness, Key Switch Options
(Not Shown - See Section 7 for Breakdown):
1
Not Required
Standard Specs
4922332
Nikken Spec
36
0902433
Bracket (Nikken/Taiyo Spec Only - Not Shown)
1
37
3740069
Relay (Nikken/Taiyo Spec Only - Not Shown)
1
ALARM INSTALLATIONS (OPTIONAL)
Ref.
0257811
Descent Alarm
Ref.
A
0257813
Motion Alarm
Ref. A
0257812
Travel Alarm
Ref.
A
101
0100048
Grease, Dialectic
A/R
102
0140042
Alarm
1
FIGURE 2-5. ELECTRICAL COMPONENT INSTALLATIONS (LEFT SIDE OF MACHINES WITH
STANDARD CONTROLS) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
