8-14 3120738
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
31 Not Available Decal - Bar Code 1
32 1704885 Decal, Website 1
— — — — — — — — — — — —
Decal Kits: A/R
Kit 1 - 2032E2 & 2646E2 Options: 1
2901579 (Prior to S/N 99138) (Includes Items 12-22)
2902071 (S/N 99138 to Present)
(Includes Items 12-20, 22, 32)
2901582 Kit 2 - 2032E2 & 2646E2 (Includes Items 24-30) 1
2902119 Kit 1 - 2632E2 (Includes Items 12-20, 32) 1
2901582 Kit 2 - 2632E2 (Includes Items 24-30) 1
Kit 1 - 3246E2 Options: 1
2901779 (Prior to S/N99138) (Includes Items 12-21)
2902072 (S/N 99138 to Present)
(Includes Items 12-20, 32)
2901582 Kit 2 - 3246E2 (Includes Items 24-30) 1
Decal Kits Complete: A/R
2900987 Kit - 2032E2 & 2646E2 (Includes Items 6-9, 102
Kits 2901579 & 2901582) 1
DECAL INSTALLATION OPTIONS (VARYING PARTS): Ref.
0257993 DECAL INSTALLATION - 2032E2 Ref. 4
0271517 DECAL INSTALLATION - 2632E2 Ref. 2
0257994 DECAL INSTALLATION - 2646E2 Ref. 4
0258937 DECAL INSTALLATION - 3246E2 Ref. 3
101 Decal Options: 2
3252567 Decal - 2032E2
1705013 Decal - 2632E2
3252568 Decal - 2646E2
3252619 Decal - 3246E2
102 2901851 Decal Kit - Wheel Load (2032E2) 1
Decal - Wheel Load Options: 4
Use 1704400 Prior to S/N 63328 (Was p/n 1703820)
1704400 S/N 63328 to Present
2901705 Decal Kit - Wheel Load (2632E2) 1
1704137 Decal - Wheel Load 4
2901852 Decal Kit - Wheel Load (2646E2) 1
Decal - Wheel Load Options: 4
Use 1704402 Prior to S/N 63328 (was p/n 1703824)
1704402 S/N 63328 to Present
2901853 Decal Kit - Wheel Load (3246E2) 1
Decal - Wheel Load Options: 4
Use 1704403 Prior to S/N 63328 (Was p/n 1704186)
1704403 S/N 63328 to Present
103 1703464 Decal - AC Power (Not Shown) 1
FIGURE 8-3. DECALS INSTALLATION - 2032E2/2632E2/2646E2/3246E2 (COMMON) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
