SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
.
FIGURE 2-1. HYDRAULIC COMPONENT INSTALLATIONS - 1532E2/1932E2
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
HYDRAULIC COMPONENTS INSTALLATIONS -
1532E2 &1932E2 (LEFT SIDE) OPTIONS:
Ref.
0258056
(Prior to S/N 90870)
Ref.
G
0271222
(S/N 90870 to Present)
Ref.
A
1
0100020
Sealant, Pipe
A/R
2
0641405
Bolt 1/4”-20NC x 5/8”
2
3
0641508
Bolt 5/16”-18NC x 1”
7
4
0902486
Bracket, Filter Mounting
1
5
0902490
Bracket, Tank
1
6
1320030
Clamp, Hose
2
7
1340052
Breather, Tank
1
8
2120105
Filter Assembly
1
2120072
Element, Filter
1
9
3311505
Locknut 5/16”-18NC
3
10
3520077
Plug, Snap
1
11
Motor/Pump Assembly Options:
1
3600288
Prior to S/N 90870
3600325
S/N 90870 to Present
11A
7011041
Motor
1
7010639
Brush
2
7010640
Spring
8
11B
Pump Options:
1
7011050
Prior to S/N 90870
7011049
S/N 90870 to Present
7011045
Gasket Kit
1
7010903
Seal, Shaft
1
11C
7010944
Coupling Kit
1
11D
7011043
Screw, Pump Mounting
4
11E
7011044
Gasket
1
12
4400415
Tank, Hydraulic
1
12A
1120491
Lid
1
12B
3780199
O-Ring
1
12C
Not Available
Plug
1
13
4420038
Tape, Rubatex
25in/64cm
14
4567681
Tube, Supply
1
15
4567682
Tube, Return
1
16
4751400
Flatwasher 1/4”
5
17
4751500
Flatwasher 5/16”
10
18
0641406
Bolt 1/4”-20NC x 3/4”
3
19
4641020
Valve Assembly (See Figure 2-3 for Breakdown)
1
20
Not Used
21
0641410
Bolt 1/4”-20NC x 1 1/4” (S/N 49355 to Present)
2
22
0641510
Bolt 5/16”-18NC x 1 1/4” (S/N 49355 to Present)
1
23
Cylinder, Cushion Options:
A/R
Not Required
Prior to S/N 49355
0
Use 1683834
S/N 49355 to S/N 65498 (Was p/n 1683560)
1
1683834
S/N 65498 to Present
1
