JLG 3246E2 ANSI Parts Manual User Manual
Page 62

2 -28
3120738
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
105
Cable, Battery (Terminal to Terminal) Options:
3
Use 1061017
Prior to S/N 112124 (Was P/N 1060665)
1061017
S/N 112124 to Present
106
Cable, Battery Options (Battery +):
1
1060668
Standard Controls
1060775
Proportional Controls
1060796
Proportional Controls (2632E2 Only) (P/N 1060796
Includes Both Items 106 & 107 as 1 Cable Assembly)
107
Cable, Battery Options (Battery –):
1
1060669
Standard Controls
1060774
Proportional Controls
1060796
Proportional Controls (2632E2 Only) (P/N 1060796
Includes Both Items 106 & 107 as 1 Cable Assembly)
108
0100051
Grease, Battery Terminal
A/R
109
3300429
Nut, Special 5/16”-18NC (Prior to S/N 112124)
8
110
4940026
Spacer, Wood
1
111
4940027
Spacer, Wood
1
112
4740474
Lockwasher, Stainless 5/16” (Prior to S/N 112124)
8
113
4922090
Harness - Ground
1
114
0902552
Bracket, Cable Mounting (2632E2 Only - Not Shown)
1
0258059
BATTERY COMPONENTS INSTALLATIONS - 1532E2/
1932E2
Ref.
D
151
Battery Options:
4
Wet Cell (Standard)
0400169
Prior to S/N 112124
0400215
S/N 112124 to Present
Not Available
Dry Cell (Standard)
152
0630526
Screw, Washer Head 5/16”-18NC x 1 1/4”
(Prior to S/N 112124)
8
153
0840031
Boot, Terminal (d shape)
7
154
0840032
Boot, Terminal (b shape) (Prior to S/N 49355)
3
155
Cable, Battery (Terminal to Terminal) Options:
3
1060665
Prior to S/N 112124
1061017
S/N 112124 to Present
156
1060681
Cable, Battery (Battery + to Fuse)
1
157
1060682
Cable, Battery (Battery - to Motor)
1
158
3300429
Nut, Special 5/16”-18NC (Prior to S/N 112124)
8
159
4740474
Lockwasher, Stainless 5/16” (Prior to S/N 112124)
8
160
4922090
Harness - Ground
1
161
4060805
Flex-Trim (S/N 61592 to Present)
5in/14cm
162
0940087
Arm, Bumper (S/N 49355 to Present)
4
163
0100051
Grease, Battery Terminal
A/R
FIGURE 2-7. ELECTRICAL COMPONENT INSTALLATIONS (RIGHT SIDE) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
