3120738
2 -31
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
.
FIGURE 2-8. BATTERY CHARGER ASSEMBLIES
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
BATTERY CHARGER ASSMBLIES OPTIONS:
Ref.
Note: Battery Charger Serial Number Nameplate located
on front of charger. To decode build date, look at first line
for Charger Spec and Date Code.
Example: BA515 (Spec) 9631 (Date Code). First and sec-
ond digits in the Date Code indicates year. Third and
fourth digits indicate the week of manufacture.
Ref.
Note: Original Equipment components may have been
replaced with Service Replacement components. Identify
the Battery Charger by the Serial Number Nameplate
before ordering parts.
Ref.
0400170
120-240V/50-60Hz (ANSI Spec Machines)
Ref.
C
100-200V/50-60Hz (Japanese Spec Machines)
Ref.
0400177
Original Equipment
Ref.
B
0400204
Service Replacement
Ref.
A
1
7018576
Bushing, Snap
4
2
Relay Options:
1
7018564
ANSI Spec
7018506
Japanese Spec
3
Not Available
Handle, Case (Not Shown - To replace purchase item
4)
1
4
7018591
Cover with Handle (Not Shown)
1
5
Case, Main Options:
1
7020606
ANSI Spec
Japanese Spec
7018596
Assy p/n 0400177
See Note
Assy p/n 0400204 (Note: Not Available for
Purchase)
6
7011509
Breaker, Circuit - DC
1
7
Breaker, Circuit - AC Options:
A/R
7018514
ANSI Spec
7018597
Japanese Spec
8
Card, Circuit Options:
1
7018578
ANSI Spec
7018598
Japanese Spec
9
7018579
Clamp
2
10
7011621
Connector - 2 Position
1
11
Cord Set - DC Options:
1
Use 7018581
ANSI Spec (was p/n 7018580)
Japanese Spec
Use 7011656
Assy p/n 0400177 (was p/n 7020604)
7022936
Assy p/n 0400204
12
DC Assembly with Plug Options:
1
7018581
ANSI Spec
Japanese Spec
7020600
Assy p/n 0400177
See Note
Assy p/n 0400204 (Note: Not Available for
Purchase)
