Cab and Covers
4.2
G5-18A/2505
4.1
OPERATOR’S CAB AND COVERS
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the machine cab and
covers. The following illustration identifies the
components that are referred to throughout this section.
MY2390
PARK BRAKE
SWITCH (G5-18A)
LSI OVERRIDE
SWITCH (2505)
SERVICE BRAKE PEDAL
JOYSTICK
TRANSMISSION
CONTROL LEVER
INSTRUMENT
PANEL
RIGHT HAND CONSOLE
PARK BRAKE LEVER (2505)
ACCELERATOR PEDAL
IGNITION SWITCH
STEERING COLUMN
ADJUSTER
(IF EQUIPPED)
QUICK ATTACH SWITCH
STEERING WHEEL
HORN BUTTON
SPEEDOMETER
(2505)
FRAME LEVEL
INDICATOR
LSI INDICATOR
(2505)
ACCESSORY CONTROL
LEVER (IF EQUIPPED)
