Page 100

Hydraulic System
8.26
G5-18A/2505
8.11.8
Hydraulic Cylinder Torque
Specifications
Description
Extend/Retract Cylinder Set Screw
60-69 lb-ft (81-94 Nm)
All Other Cylinder Set Screws
16-18 lb-ft (22-25 Nm)
Counter Balance Valves
45-50 lb-ft (61-68 Nm)
Lift/Lower Cylinder
Head Gland
300-400 lb-ft (406-542 Nm)
Piston
1800-2000 lb-ft (2440-2712 Nm)
Extend/Retract Cylinder
Head Gland
200-250 lb-ft (271-339 Nm)
Piston
200-240 lb-ft (271-325 Nm)
Tilt Cylinder
Head Gland
300-400 lb-ft (406-542 Nm)
Piston
1400-1500 lb-ft (1898-2034 Nm)
Compensating Cylinder
Head Gland
300-400 lb-ft (406-542 Nm)
Piston
1400-1500 lb-ft (1898-2034 Nm)
Use Loctite
®
271 or Equivalent on all Piston Applications
Use Loctite
®
243 or Equivalent on all Set Screws
