JLG 45ic ANSI Parts Manual User Manual
Page 9
3120735
1-3
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-1. FRAME AND STEERING INSTALLATIONS.
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
FRAME WELDMENT OPTIONS:
Ref.
2360402
Model 40ic
2360403
Model 45ic
STEERING AND SPINDLES INSTALLATION
Ref.
0256855
(ANSI Spec)
Ref.
-/3
0252856
(CSA Spec)
Ref.
B/3
1
2780201
Hub Assembly (See Items 101-105 for Breakdown)
2
2
Not Used
3
3421988
Kingpin
2
4
3450810
Pin, Cotter 1/4" x 2 1/3"
2
5
3313003
Nut, Slotted 1 1/4 -7NC
2
6
0440162
Washer, Thrust
2
7
0642016
Bolt 5/8"-11NC x 2"
2
8
3312005
Locknut 5/8"-11NC
2
9
3841146
End, Rod
2
10
3322002
Nut, Jam 5/8"-18NF
2
11
1683487
Steer Cylinder Assembly (See Section 5 for
Breakdown)
1
12
3340644
Pad, Wear
1
13
3020022
Grease
A/R
14
4070809
Shim
A/R
15
4712400
Flatwasher 7/8"
2
16
3450506
Pin, Cotter
2
17
3780182
O-Ring
4
18
0641510
Bolt 5/16"-18NC x 1 1/4"
1
19
4751500
Flatwasher 5/16"
1
20
3311505
Locknut 5/16"-18NC
1
21
0630016
Bolt, Wheel 1/2"-20NF x 1"
12
22
4060808
Trim
2 Ft/.61m
23
1120457
Cap, Dust
2
24 to 51
Not Used
52
Spindle Weldment Options:
(See Items 201-202 for Breakdown)
2
4130319
ANSI Spec
4130302
CSA Spec
