JLG 45ic ANSI Parts Manual - Manual (Page 132)

7-2 3120735
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-1. ELECTRICAL DIAGRAMS AND DIAGRAM LIST.
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
ELECTRICAL COMPONENTS AND DIAGRAMS LIST Ref.
Note: Items with * indicate electrical drawings
shown in this manual. All other electrical drawings
are available from JLG Service Department upon
request.
2901249/4932338 ALARM ELECTRICAL COMPONENTS (MOTION) Ref. –/–
(OPTIONAL - DOMESTIC & LATIN AMERICA/
STANDARD - JAPANESE)
0140026 Alarm 1
4932866/1282596 ALARM ELECTRICAL COMPONENTS (TILT) Ref. –/B
(OPTIONAL - DOMESTIC & LATIN AMERICA/
STANDARD - JAPANESE)
4921425 Harness 1
0140031 Alarm 1
4392338 BEACON ELECTRICAL DIAGRAM Ref. C
1282596 DRIVE CUT-OUT ELECTRICAL DIAGRAMS Ref. B
4932859 ABOVE ELEVATION (B/M ONLY) Ref.
4932860 ABOVE ELEVATION TILT (B/M ONLY) Ref.
4932838
GROUND CONTROL BOX ELECTRICAL
DIAGRAM
Ref. E/5
3730099 Resistor - 20 Ohm/12Watts 1
3990010 Diode 6 Amp 12
0256524 LIGHT PANEL ELECTRICAL DIAGRAM Ref. A
4932868/1282596 OVERLOAD WITHOUT OVERRIDE ELECTRICAL Ref. –/B
DIAGRAM (JAPANESE SPEC)
Note: Additional Components Listed in Section 10.
3740119 Relay, Timer 1
4120014 Base, Relay 1
4160114 Spring, Relay 1
3990010 Diode 3
4932844 PLATFORM ELECTRICAL DIAGRAM Ref. 8
2901406
PLATFORM WORKLIGHTS ELECTRICAL
DIAGRAM
Ref. –
4921428 Harness 1
2920140 Worklight 2
4360070 Breaker, Circuit - 15 Amp 1
1870040* STANDARD ELECTRICAL SCHEMATIC Ref. K
