JLG 45ic ANSI Parts Manual User Manual
Page 14

1-8
3120735
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
100 (cont’d)
4520159
Tire and Wheel Assembly (Solid - Non-Marking)
4
(Sold As An Assembly Only)
TIRE AND WHEEL ASSEMBLY (PNEUMATIC)
MODEL 40ic
Ref.
0256834
TIRE AND WHEEL ASSEMBLY (G78-15x28
Ref.
–
PNEUMATIC WITH 6" WIDE RIM)
0256640
TIRE AND WHEEL ASSEMBLY (G78-15x28
Ref.
A
PNEUMATIC WITH 8" WIDE RIM)
0256952
TIRE AND WHEEL ASSEMBLY (10x16.5
PNEUMATIC RIGHT SIDE)
Ref.
–
0256954
TIRE AND WHEEL ASSEMBLY (10x16.5
PNEUMATIC LEFT SIDE)
Ref.
–
151
Tire Options (1 Per Assembly):
4
4520184
Tire - G78-15 x 28
4520190
Tire - 10 x 16.5
152
Rim Options (1 Per Assembly):
4
4860169
Rim - 6" Wide (G78-15 x 28 Tires)
4860137
Rim - 8" Wide (G78-15 x 28 Tires)
4860168
Rim (10 x 16.5 Tires)
153
4640392
Stem, Valve (G78-15 x 28 Tires) (1 Per Assembly)
4
4640113
Stem, Valve (10 x 16.5 Tires) (1 Per Assembly)
4
154
1701812
Decal - Tire Pressure (1 Per Assembly)
4
TIRE AND WHEEL INSTALLATIONS - MODEL 45ic
Ref.
0254484
LT215/85RI6 PNEUMATIC TIRE
Ref.
–
0256967
10 X 16.5 PNEUMATIC TIRE
Ref.
–
0254866
LT215/85RI6 FOAM-FILLED TIRE
Ref.
–
0256968
10 X 16.5 FOAM-FILLED TIRE
Ref.
–
0254874
SOLID - NON-MARKING TIRE (OPTIONAL)
Ref.
–
Note: Assemblies may require ballast/foam fill-
ing to manufacturer’s specifications prior to
installing on a machine. Refer to Operation &
Safety or Service & Maintenance Manuals. Pur-
chase individual tire and/or rim only if able to
foam fill tire & wheel assembly, otherwise, pur-
chase complete assembly.
200
0254481
Tire and Wheel Assembly (LT215/85RI6
Pneumatic) (Includes Items 251-254)
3
0256952
Tire and Wheel Assembly (10 X 16.5 Pneumatic
2
Right Side) (Includes Items 251-254)
0256954
Tire and Wheel Assembly (10 X 16.5 Pneumatic
2
Left Side) (Includes Items 251-254)
0254865
Tire and Wheel Assembly (LT215/85RI6 Foam-
Filled) (Sold As An Assembly Only)
2
0256953
Tire and Wheel Assembly (10 X 16.5 Foam-Filled
2
Right Side) (Sold As An Assembly Only)
0256955
Tire and Wheel Assembly (10 X 16.5 Foam-Filled
2
Left Side) (Sold As An Assembly Only)
FIGURE 1-2. TIRE AND WHEEL DRIVE INSTALLATIONS. (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
