SECTION 1 FRAME
FIGURE 1-9. DUAL FUEL INSTALLATION (OPTION FOR VANGUARD GAS MACHINES).
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
2901456
DUAL FUEL KIT ASSEMBLY
Ref.
A
1
3720011
Regulator, Beam
1
2
7017513
Fitting, 90°
1
3
7017517
Fitting, 90° Barbed
1
4
7017518
Fitting, 90°
1
5
7017508
Bushing
1
6
7017501
Thermostat
1
7
7017519
Fitting, Straight Barbed
1
8
7017514
Fitting, 90° (Prior to S/N 37463)
1
7017522
Fitting, 90° (S/N 37463 to Present)
1
9
7017500
Solenoid, Fuel Shut-Off
1
10
7017520
Fitting, Straight Nipple
1
11
7017521
Fitting, 90°
3
12
Not Available
Hose, Vapor
12in/30.5cm
13
Not Available
Hose, Water
16in/41cm
14
Not Available
Hose, Water
22in/59cm
15
Not Available
Hose, Vacuum
20in/51cm
16
Not Available
Clamp
2
17
Not Available
Clamp
4
18
7017512
Fitting, Tee
1
19
Not Available
Tie-Strap
1
20
7017511
Adapter
1
21
7017510
Venturi
1
22
7017513
Fitting, 90°
1
23
7017504
Filter, Fuel
1
24
7017521
Fitting, 90°
1
25
7017505
Valve, Relief
1
26
Not Used
27
Not Available
Clamp (Not Shown)
2
28
7017521
Fitting, 90° (Not Shown - Located at Oil Pressure
Switch)
1
0256000
DUAL FUEL INSTALLATION
Ref.
G
101
2901456
Dual Fuel Kit Assembly (Includes Items 1-28)
1
102
2720175
Hose
1
103
2720190
Hose
1
104
2180387
Fitting, Tank Connector
1
105
Not Used
106
4360336
Switch, Toggle (Not Shown - Located at Platform
Box)
1
107
4060802
Guard, Switch (Not Shown - Located at Platform Box)
1
108
3790012
O-Ring (Not Shown - Located at Platform Box)
1
109
1701543
Decal - LP (Not Shown - Located near Tank)
1
110
1700818
Decal - Liquid Withdrawal (Not Shown - Located near
1
Tank)
111
2720433
Hose
2
112
1320016
Clamp
2
