SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-3. LOWER LIFT CYLINDER ASSEMBLIES. (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
LOWER LIFT CYLINDER ASSEMBLY - MODEL 40IC Ref.
1682855 Lower Lift Cylinder Assembly - Model 40ic Ref. C
(Prior to S/N 33090)
1683518 Lower Lift Cylinder Assembly - Model 40ic Ref. 1/A
(S/N 33090 To Present)
101 Not Used
102 1682858 Rod Weldment 1
102A 0961726 Bushing, Teflon 2
103 1120305 Retainer 1
104 3480113 Piston 1
105 1682209 Head 1
106 3300281 Nut, Hex 1
107 4740207 Washer 1
108 4565992 Spacer 1
109 4640634 Cartridge, Holding Valve 1
2900770 Seal Kit - 4640634 Valve 1
110 4640816 Cartridge, Holding Valve 1
2900770 Seal Kit - 4640816 Valve 1
111 2220885 Plug 2
112 3900170 Setscrew 3/8"-16NC x 3/8" 1
113 Not Used
114 Kit Ring, Lock 2
115 Kit Seal, Piston 2
116 Kit O-Ring 1
117 Kit Ring, Wear 1
118 Kit O-Ring 1
Kit Ring, Back-up 1
119 Kit Seal, Rod 1
120 Kit Wiper, Rod 1
121 0100011 Loctite #242 A/R
122 0100038 Primer, Locking A/R
123 0100035 Loctite #222 A/R
124 to 150 Not Used
151 Barrel Weldment Options:
1682856 (Prior to S/N 33090)
1683512 (S/N 33090 to Present)
151A 0961726 Bushing, Teflon 2
