JLG 45ic ANSI Parts Manual User Manual
Page 80

3-4
3120735
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
52
Link, Level (Base and Mid) Options:
2
4844302
Model 40 ic
4844541
Model 45 ic
0961726
Bushing, Teflon (4 Per Assembly)
8
53
Upright Weldment (Bottom) Options:
1
4844303
Model 40 ic
4844427
Model 45 ic
54
Not Used
55
Main Boom Assembly (See Figure 3-2 for Break-
down) Options:
1
0800832
Model 40 ic
0800853
Model 45 ic
56
Plate, Hose Guard Options:
1
3536491
Model 40 ic
3537045
Model 45 ic
57
Cylinder Assembly - Lower Lift Options: (See Section
5 for Breakdown)
1
1682855
Model 40 ic (Prior to S/N 29899)
1683518
(S/N 29899 to Present)
1683013
Model 45 ic (Prior to S/N 29899)
1683521
(S/N 29899 to Present)
58
Cylinder Assembly - Mid Lift Options: (See Section 5
for Breakdown)
1
1682861
Model 40 ic (Prior to S/N 29899)
1683519
(S/N 29899 to Present)
1683018
Model 45 ic (Prior to S/N 29899)
1683522
(S/N 29899 to Present)
59
Tube Options:
1
4566427
Model 40 ic
4566356
Model 45 ic
0254875
BOOM LIMIT SWITCHES INSTALLATION
Ref.
4
101
4360321
Switch, Limit
2
102
4460428
Connector, Strain Relief
2
103
3311005
Locknut #10-24NC
4
104
Not Used
105
3900168
Screw, Socket Head #10-24NC x 1 1/2"
2
106
3900097
Screw, Socket Head #10-24NC x 2 1/8"
2
107
1060341
Cable, Electrical - 16/2
48’14.7m
108
1670832
Cover, Lower Switch
1
109
1680833
Cover, Upper Switch
1
FIGURE 3-1. BOOM AND LIMIT SWITCHES INSTALLATIONS. (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
