SECTION 7 ELECTRICAL
134 to 150 Not Used
151
Harness Assembly - 16/30 Options: (Main Boom)
(Includes Items 101 to 104)
1
4921840 Model 40ic
4921841 Model 45ic
152
Harness Assembly - 16/30 Options: (Tower Boom)
(Includes Items 201 to 210)
1
4921581 Model 40ic
4921591 Model 45ic
153
Harness Assembly - 12/4 Options: (Main Boom)
(Includes Items 301 to 304)
1
4921846 Model 40ic
4921847 Model 45ic
154
Harness Assembly - 12/4 Options: (Tower Boom)
(Includes Items 401 to 404)
1
4921844 Model 40ic
4921845 Model 45ic
4921840 HARNESS ASSEMBLY - 16/30 (MAIN BOOM) (40ic) Ref. –
4921841 HARNESS ASSEMBLY - 16/30 (MAIN BOOM) (45ic) Ref. –
201 Use 1060516 Cable, Electrical - 16/30 (Was P/N 1060229) A/R
Model 40ic 26 ft./8m
Model 45ic 27.5 ft./8.4m
202 4460501 Connector - 31 Pin (Female) 1
203 4460464 Pin, Male 30
204 4450466 Seal, Terminal 1
4921581
HARNESS ASSEMBLY - 16/30 (TOWER BOOM)
(40ic)
Ref. A
4921591
HARNESS ASSEMBLY - 16/30 (TOWER BOOM)
(45ic)
Ref. A
301 Use 1060516 Cable, Electrical - 16/30 (Was P/N 1060229) A/R
Model 40ic 36 ft./11m
Model 45ic 42 ft./13m
302 Not Used
303 4460500 Connector - 31 Pin (Male) 1
304 4460465 Socket, Female 30
305 4460466 Seal, Terminal 1
306 Not Used
307 4460470 Nut, Receptacle (Model 40ic Only) 1
308 4460471 Lockwasher, Receptacle (Model 40ic Only) 1
FIGURE 7-3. HARNESS INSTALLATIONS. (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
