JLG 45ic ANSI Parts Manual User Manual
Page 22

1-16
3120735
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
0920084
DRIVE BRAKE ASSEMBLY - MICO PRIOR TO S/N
33476)
Ref.
–
0920110
DRIVE BRAKE ASSEMBLY - MICO S/N 33476 TO
PRESENT ALL INSTALLATIONS REQUIRE
(2) GASKETS
Ref.
A
51
Shaft Options:
1
7011712
Prior to S/N 33476
7011720
S/N 33476 to Present
52
Spring (Inner) Options:
6
7007979
Prior to S/N 33476
7007970
S/N 33476 to Present
53
Spring (Outer) Options:
7007980
Prior to S/N 33476
6
7018602
S/N 33476 to Present
3
54
Housing Options:
1
7011713
Prior to S/N 33476
7018605
S/N 33476 to Present
55
Bolt, Washer Head Options:
4
7007985
Prior to S/N 33476
7018607
S/N 33476 to Present
56
Guide, Spring Options:
1
7011717
Prior to S/N 33476
7018606
S/N 33476 to Present
57
Piston Options:
1
7007923
Prior to S/N 33476
7018603
S/N 33476 to Present
58
Kit
Plate, Return
1
7011715
Separator Assembly
2
7011714
Pin
4
7007983
Separator
2
59
Screw, Bleeder Options:
1
7007914
Prior to S/N 33476
7018609
S/N 33476 to Present
Lining Kit (Includes Items 58,11, 22, 23, 28 and 29)
Options:
1
2900767
Prior to S/N 33476
7018608
S/N 33476 to Present
FIGURE 1-5. DRIVE BRAKE ASSEMBLY. (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
