JLG 45ic ANSI Parts Manual User Manual
Page 88

4-4
3120735
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
PLATFORM WELDMENT OPTIONS:
Ref.
3510504
26" x 48" (Prior to S/N 33712)
Ref.
–
3510596
26" x 48" (S/N 33712 to Present)
Ref.
B/2
3510498
26" x 60" (Prior to S/N 33712)
Ref.
–
3510584
26" x 60" (S/N 33712 to Present)
Ref.
A/1
3510601
26" x 48" (With Mesh to Top Rail)
Ref.
A/2
3510513
26" x 60" (With Mesh to Top Rail)
(Prior to S/N 33712)
Ref.
A/2
3510598
26" x 60" (With Mesh to Top Rail)
Ref.
A/3
(S/N 33712 to Present)
Note: Replacement decals must be ordered sepa-
rately - See Section 8.
101
Door Weldment Options (Includes Items 102-107):
1
1780265
Standard Door (Prior to S/N 33712)
1780299
Standard Door (S/N 33712 to Present)
1780289
Door With Mesh to Top Rail (Prior to S/N 33712)
1780300
Door With Mesh to Top Rail (S/N 33712 to
Present)
102
2940006
Latch, Door (Prior to S/N 33712)
1
2560010
Handle, Door (Prior to S/N 33712)
1
103
2940074
Latch, Door (S/N 33712 to Present)
1
104
3911016
Screw, Machine #10-24NC x 1"
4
105
4761000
Lockwasher #10
4
106
4751000
Flatwasher #10
4
107
3311001
Nut #10-24NC
4
0252408
FOOTSWITCH INSTALLATION
Ref.
D
201
4360031
Footswitch Assembly
1
7000625
Block, Contact
2
202
4460422
Connector
1
203
0641408
Bolt 1/4"-20NC x 1"
3
204
3311401
Nut 1/4"-20NC
3
205
4751400
Flatwasher 1/4"
3
206
Not Used
207
4060803
Flex-Trim
2 in./5cm
OPTIONAL 110VAC RECEPTACLE BOX
INSTALLATION
Ref.
0253716
Model 40 ic
Ref.
E
0254042
Model 45 ic
Ref.
D
301
0860038
Box, Electrical
1
302
4460347
Receptacle, Electrical
1
303
4060092
Cover, Receptacle
1
304
4460071
Connector, Strain Relief
1
305
4460205
Plug
1
306
Not Used
307
3910606
Screw, Machine #6-32NC x 3/8"
4
FIGURE 4-1. PLATFORM COMPONENTS INSTALLATION. (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
