3120804 1-1
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
TABLE OF CONTENTS
FIGURE DESCRIPTION PAGE
1-1 FRAME, STEERING & DRIVE COMPONENTS, ASSEMBLIES & INSTALLATIONS - FIXED
& OSCILLATING AXLES (STANDARD 2WD - DOUBLE ACTING STEER CYLINDER) . . . . . . 1-2
1-2 FRAME, STEERING & DRIVE COMPONENTS, ASSEMBLIES & INSTALLATIONS - FIXED
& OSCILLATING AXLES (OPTIONAL 2WD - SINGLE ACTING STEER CYLINDER) . . . . . . . . 1-6
1-3 FRAME, STEERING & DRIVE COMPONENTS, ASSEMBLIES & INSTALLATIONS - FIXED
& OSCILLATING AXLES (4WD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
1-4 DRIVE HUB ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
1-5 DRIVE HUB/BRAKE ASSEMBLY (4WD FRONT) (PRIOR TO DECEMBER 1991) . . . . . . . . . . 1-20
1-6 DRIVE HUB/BRAKE ASSEMBLY (4WD FRONT) (DECEMBER 1991 TO PRESENT) . . . . . . . 1-24
1-7 DRIVE BRAKE ASSEMBLY (PRIOR TO DECEMBER 1991) . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-28
1-8 DRIVE BRAKE ASSEMBLY (DECEMBER 1991 TO S/N 33476) . . . . . . . . . . . . . . . . . . . . . . . . 1-30
1-9 DRIVE BRAKE ASSEMBLY (TO S/N 33476 TO S/N 56992) . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-32
1-10 DRIVE MOTOR ASSEMBLY (GAS & DIESEL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-34
1-11 DRIVE MOTOR ASSEMBLY (ELECTRIC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-36
1-12 VALVE INSTALLATION (FRAME MOUNTED) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-42
1-13 TOW PACKAGE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-44
