FIGURE 6-2. HYDRAULIC DIAGRAM - DRIVE (2WD)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
HYDRAULIC DIAGRAMS - DRIVE (2WD)
2791647
2m Frame 2WD - Deutz (With Swivel)
Ref.
E
2791689
1.75m Frame 2WD - Deutz (With Swivel)
Ref.
E
2792061
2m Frame - With 12” x 16.5” Tires (With Swivel)
Ref.
1
2210003
Fitting, Barbed
1
2
2220646
Fitting, 90
1
3
1320023
Clamp
4
4
2720353
Hose, Suction (Prior to March 1993)
1
2720357
Hose, Suction (March 1993 to Present)
1
5
2210014
Fitting, 90
Barbed
1
6
2220375
Fitting, Straight
1
7
2220385
Fitting, Tee
1
8
2220618
Fitting, Reducer
1
9
2220605
Fitting, Tee
1
10
2750979
Hose
1
11
Not Used
12
2751014
Hose
1
13
2220417
Fitting, Straight (Prior to March 1993)
2
2220582
Fitting, Straight (March 1993 to Present)
2
14
2751427
Hose
1
15
2220468
Fitting, Straight
1
16
2751631
Hose
1
17
2220457
Fitting, Straight
5
18
2220365
Fitting, 45
2
19
2752319
Hose
2
20
2220348
Fitting, Straight
4
21
2751010
Hose
1
22
2220582
Fitting, Straight (Prior to April 1992)
1
23
2220585
Fitting, 90
(Prior to March 1993)
1
2220472
Fitting, 90
(March 1993 to Present)
1
24
2220408
Fitting, Straight
2
25
2751614
Hose
2
26
2220578
Fitting, 90
1
27
2750760
Hose
1
28
2220414
Fitting, Straight
2
29
Not Used
30
Hose Options:
1
2752317
2m Frame 2WD
2752323
1.75m Frame 2WD
2752324
With 12” x 16.5 Tires
31
Not Used
32
Hose Options:
1
2752320
2m & 1.75m Frame 2WD
2752329
With 12” x 16.5 Tires
33
2220363
Fitting, Tee
