Page 267
3120804
9-1
S
E
C
T
I
O
N
9
R
E
C
O
M
M
E
N
D
E
D
S
E
R
V
I
C
E
P
A
R
T
S
S
T
O
C
K
SECTION 9 RECOMMENDED SERVICE PARTS STOCK
MODEL 34HA
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10
10-20
20 OR MORE
STANDARD PARTS
2120125
Element, Filter (Figure 2-1)
4
8
12
7000417
Coil (Figure 2-2)
1
1
1
7000418
Coil (Figure 2-2,2-3 & 2-5)
1
1
1
7002450
Coil (Figure 2-2)
1
1
1
7010711
Coil (Figure 2-4)
1
1
1
7009742
Coil (Figure 2-6)
1
1
1
7004214
Element, Air Cleaner (Figures 2-12, 2-13 & 2-16)
1 Dozen
1 Dozen
1 Dozen
3740067
Relay (Figures 2-18)
1
1
1
3740035
Relay (Figures 2-20)
1
1
1
4360232
Breaker, Circuit 15Amp (Figures 2-20, 2-26)
1
1
1
2120110
Element, Hydraulic Filter (Figure 2-25)
4
8
12
1340046
Breather, Hydraulic Tank (Figure 2-25)
1
2
3
4360003
Switch, Key (Master Switch) (Figure 2-26)
1
1
1
4360073
Switch, Toggle Center Off (Figures 2-26)
1
1
1
4360199
Switch, Toggle (Figures 2-26, 4-5 & 4-6)
1
1
1
4360274
Switch, Push Button (Figures 2-26, 4-5, 4-6 & 4-7)
1
1
1
4360202
Switch, Toggle (Figures 2-26, 4-5 & 4-6)
1
1
1
4360200
Switch, Toggle (Figures 2-26, 4-5 & 4-6)
1
1
1
3740049
Relay (Figures 2-26, 4-5, 4-6, 4-7 & 7-1)
1
1
1
4360216
Breaker, Circuit 30Amp (Figures 2-26)
1
1
1
3740058
Relay (Figures 2-26 & 4-5)
1
1
1
3740077
Relay (Figures 2-26)
1
1
1
4360212
Breaker, Circuit (Figures 2-26)
1
1
1
3740048
Relay (Figures 2-26)
1
1
1
4360171
Switch, Tilt Indicator (Figure 2-27)
1
1
1
4360031
Footswitch (Figure 4-1 & 4-2)
1
1
1
4360209
Breaker, Circuit (Figures 4-5 & 4-6)
1
1
1
4360327
Switch, Potentiometer (Figure 4-5)
1
1
1
4360289
Switch, Push/Pull (Figure 4-6)
1
1
1
4360282
Block, Contact (Figure 4-6)
1
1
1
4360215
Switch, Proximity (Figure 4-7)
1
1
1
3990010
Diode - 6 Amp (Figure 7-1)
2
2
2
3730003
Resistor (Figure 7-1)
1
1
1
