JLG 34HA Parts Manual User Manual
Page 17
3120804
1-9
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
67
Seal, Hub Options:
2
3960373
1.75m Machines
3960098
2m Machines
68
Nut, Slotted Options:
2
3323003
Nut, Slotted 1 1/4”-12NF (1.75m Machines)
3313403
Nut, Slotted 1 1/2”-6NF (2m Machines)
69
Pin, Cotter Options:
2
3450609
Pin, Cotter 3/16”-2 1/4” (5’-9” Machines)
3451012
Pin, Cotter 5/16”-3” (2m Machines) (Prior to June 1994)
3451010
Pin, Cotter 5/16”-2 1/2” (2m Machines) (June 1994 to
Present)
70
Pin, King Options:
2
3421340
1.75m Machines
3421243
2m Machines (Prior to S/N 27273)
3422261
2m Machines (S/N 27273 to Present)
71
Washer, Thrust Options:
2
0440162
1.75m Machines
0440183
2m Machines
72
3431622
Pin, Clevis
1
73
Pin, Cotter
1
3450606
Prior to September 1991
3450608
September 1991 to Present
74
4712600
Flatwasher 1” (Narrow)
1
75
0440091
Washer, Thrust
3
76
Bolt Options:
2
0642628
Bolt 1”-8NC x 3 1/2” (5’-9” Machines)
0630425
Bolt 1”-8NC x 3 3/4” (2m Machines)
77
End, Tie-Rod (Right Side) Options:
1
0560805
1.75m Machines
0560605
2m Machines
78
3312602
Nut, Jam 1”-8NC
2
79
3300175
Locknut 1”-14NC
1
80
End, Tie-Rod (Left Side) Options:
1
0560804
1.75m Machines
0560714
2m Machines
81
3300229
Nut, Jam 1 1/4”-12NF (Left Hand Threads)
1
82
3323002
Nut, Jam 1 1/4”-12NF (Right Hand Threads)
1
83
2160003
Fitting, Grease 45
3
84
4640812
Valve, Relief (2m Machines Only)
2
85
3780183
O-Ring (2m Machines Only)
4
FIGURE 1-2. FRAME, STEERING & DRIVE COMPONENTS, ASSEMBLIES & INSTALLATIONS -
FIXED & OSCILLATING AXLES (OPTIONAL 2WD - SINGLE ACTING STEER CYLINDER)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
